DC Output Quality

For those of you that are curious as to some of the reasoning and equipment behind our PSU testing program here at The FPS Review, we have put together an introduction for you that shares a lot of the behind the scenes of the program. This program is based on what the author developed at [H]ardOCP and utilizes the equipment bequeathed to the author by Kyle Bennett. The testing we are conducting today is exactly as described in that document and will continue with our examination of the DC Output Quality.

Control Test Graphing

This image is the blank background control test on an unused connector from our SM-8800 during the testing of the Fractal Design ION+ 560P. This lets us determine what the background noise looks like during testing.

120v Input

100v Input

Test #1 is equal to approximately 25% of the rated capacity of the Fractal Design ION+ 560P at 45c. This makes Test #1 equal to 148W by loading the 12v rail to 10a, the 5v rail to 2a, the 3.3v rail to 1a, the +5vsb to 2a, and the -12v to 0.3a. TheFractal Design ION+ 560P is starting off in excellent shape as all of the rails we monitor are peaking at less than ~10mV of ripple/noise.

120v Input

100v Input

Test #2 is equal to approximately 50% of the rated capacity of the Fractal Design ION+ 560P at 45c. This makes Test #2 equal to 277W by loading the 12v rails to 20a, the 5v rail to 3a, the 3.3v rail to 2a, the +5vsb to 2a, and the -12v to 0.3a. Test #2 sees minor changes as the 5v and 3.3v rails are coming in at less than ~10mV of ripple/noise still and the 12v rail is peaking at ~10mV of ripple/noise.

120v Input

100v Input

Test #3 is equal to approximately 75% of the rated capacity of Fractal Design ION+ 560P at 45c. This makes Test #3 equal to 406W by loading the 12v rails to 30a, the 5v rail to 4a, the 3.3v rail to 3a, the +5vsb to 2a, and the -12v to 0.3a. Test #3 sees the 12v and 5v rails coming in at a peak of ~10mV of ripple/noise while the 3.3v rail is still hitting less than ~10mV of ripple/noise.

120v Input

100v Input

Test #4 is equal to approximately 100% of the rated capacity of the Fractal Design ION+ 560P at 45c. This makes Test #4 equal to 546/545W by loading the 12v rail to 40a, the 5v rail to 7a, the 3.3v rail to 5a, the +5vsb to 2a, and the -12v to 0.3a. In the final regular test, we see the 12v rail peaking at ~20mV of ripple/noise while the minor rails are peaking at ~15mV of ripple/noise on the 5v rail and ~10mV on the 3.3v rail.

Torture Test

The Torture Test is equal to approximately 80% of the rated capacity of the Fractal Design ION+ 560P at 45C. This makes the Torture Test equal to 443W by loading the 12v rail to 31a, the 5v rail to 8a, the 3.3v rail to 5a, the +5vsb to 2a, and the -12v to 0.3a. At the end of the Torture Test, we see the 12v rail peaking at ~15mV of ripple/noise while the 5v rail is peaking at ~15mV of ripple/noise and the 3.3v rail is peaking at less than ~10mV of ripple/noise.

DC Output Quality Summary

The overall DC Output Quality of the Fractal Design ION+ 560P is excellent. The ION+ 560P ended up posting a peak trace amplitude on the 12v rail of ~20mV followed by ~15mV on the 5v rail and ~10mV on the 3.3v rail. The worst relative value among these is well below ~50% of the ATX12v specification limit. On top of that, this unit was better than the BitFenix Formula Gold 550W we saw previously. Overall then, a most excellent turn of events. Let’s move on now and see how all of this wraps up!
