ASRock X870E Taichi White
Newegg
Amazon.com | Motherboard Basics | |
|---|---|
| Manufacturer | |
| Manufacturer Part Number | |
| UPC | |
| Manufacturer Product Page | Product Page |
| Chipset Platform | |
|---|---|
| Platform | AMD |
| Socket | AM5 |
| PCIe Version Support | PCIe 5.0 |
| IO Connectivity | |
|---|---|
| Expansion Slots | 2x PCIe x16 PCIe 5.0 (CPU) |
| USB Ports | 2x USB 4 (40Gbps) Rear (Type C) 1x USB 3 Gen 2x2 (20Gbps) Internal Header 5x USB 3 Gen 2 (10Gbps) Rear (Type A) 3x USB 3 Gen 1 (5Gpbs) Rear (Type A) 4x USB 3 Gen 1 (5Gpbs) Internal Header 2x USB 2.0 Rear (Type A) 4x USB 2.0 Internal Header |
| Memory | |
|---|---|
| Memory Standard | DDR5 |
| Memory Slots | 4 |
| Max Memory Supported | 256 GB |
| Storage | |
|---|---|
| M.2 Slots | 1x PCIe 5.0 (CPU) 3x PCIe 4.0 (Chipset) |
| SATA Ports | 3 |
| Networking | |
|---|---|
| LAN Ports | 1x Intel 211 - 10Gbps |
| WiFi Networking Version | WiFi 7 |
| Bluetooth Version | Bluetooth 5.4 |
| Dimensions | |
|---|---|
| Form Factor | EATX |
| Length | 305 mm |
| Width | 267 mm |
| Power Delivery | |
|---|---|
| Power Delivery | 24 Phase VCORE (110) 2 Phase SOC (110) 1 Phase MISC |
| Fan Headers | |
|---|---|
| Fan Headers | 2x CPU 1x Pump 4x 4-pin PWM 1x 3-pin 12v |
| RGB | |
|---|---|
| RGB Headers | 3x ARGB v2 1x RGB |
