JONSBO Announces HX5230 CPU Cooler Featuring 5 Heat Pipes and Is Rated for Up to 230W of Heat Dissipation

The FPS Review may receive a commission if you purchase something after clicking a link in this article.


JONSBO has announced its HX5230 high-performance CPU cooler featuring 5x 6mm heat pipes, a max airflow of 83.04 CFM, and is rated for up to 230 Watts. Speeds for the 120mm x 120mm x 25mm 4-pin PWM fan range from 700 – 1800 RPM with noise levels listed as 25.2-37.6 dBa. It is paired with a 55-fin heat sink whose 128mm (L) x 75mm (W) x 158mm (H) dimensions equate to a heat dissipation area of 7,000 cm2. The all-black design does not have any RGB making it a perfect option for those interested in avoiding a light show while keeping a clean look.

Other features include a maximum static pressure of 2.68 mm H20 for the fan which uses an FDB bearing, a copper base plate, and an estimated lifespan of over 50,000 hours @25℃. The HX5230 weighs 704g, uses 2.4W, and is compatible with INTEL LGA 115X/1200 / 1700 and AMD AM4/AM5 sockets. The installation kit also includes Thermal Grizzly Hydronaut thermal paste. Pricing has not been announced.


  • Model: HX5230
  • Radiator size: 128 mm(L) x 75mm(W) x 158mm(H)
  • Heat pipe size: Φ 6mm 5 PCS
  • D-TDP: 230W
  • Fan size: 120mm x 120mm x 25mm
  • Fan RPM: 700 -1800RPM(±10%)
  • Fan air volume: 32.47-83.04 CFM(MAX)
  • Fan pressure: 0.47-2.68mm H2O(MAX)
  • Fan noise: 25.2-37.6dB(A)(MAX)
  • Fan bearing: FDB bearing
  • Lifespan: ≥50000h @25℃
  • Interface: FAN 4-Pin PWM
  • Working current: 0.20A
  • Working voltage: 12V DC
  • Power Consumption: 2.4W
  • Support range: INTEL: LGA 115X/1200 / 1700 AMD: AM4/AM5
  • Total net weight: 704g


JONSBO is probably not a familiar name to many in North America but it has been making PC products for over ten years now. Its products are available in Europe and Asia and are focused on PC gaming and include CPU coolers (AIOs and air-cooled), PC chassis, and other PC accessories.

From JONSBO (machine translated):

“The JONSBO brand was founded by like-minded players in the circle. Based on the ultimate goal of meeting the real needs of players, it provides players with integrated solutions for computer hosts.

JONSBO products are sold all over the world in the name of reasonable design, high-quality materials, exquisite workmanship, and outstanding cost performance in China, and have won a good reputation and many awards and honors in many countries such as South Korea, Japan, and the European Union. Relying on the brand operation of its own factory integrating design, development, manufacturing, and sales, as well as the accumulation of more than ten years of hard work in the hardware industry and the accumulation of a good market reputation, it provides OEM or ODM for well-known brands in Japan, Germany, Sweden, and other countries Serve and occupy a large market share in the server field and have won unanimous praise from friends and businessmen.

Since its development, JONSBO has firmly maintained its original intention of designing and producing products that meet the real needs of players. It takes the needs of players as the starting point for design and cooperates with superior materials and exquisite craftsmanship to work hand in hand with players in the field of computer hardware to create a better future.”
